High Temperature Resistance FeCrAl Woven Wire Mesh
FeCrAl wire mesh is mainly used as the drying and heating equipment in metallurgy, colliery, dyeing, food factory, hospital, high density board factory and cardboard.
The FeCrAl wire mesh is an ideal heating resistance material in the industry electric furnace, household appliances, gas burners and infrared device.
There are still FeCrAl expanded heaters and FeCrAl perforated heaters.
FeCrAl is also used in these place:
Gas burners,
Catalysts
Electronic engineering
Heat processing
E-cigarette atomizers
Furnace curtains
Furnace Filters
Heat Resistance FeCrAl Wire Mesh
Material:1Cr13Al4， 0Cr23Al5， 0Cr25Al5
Mesh Counts: 2-200 mesh
Wire Diameter: 0.02-2 mm and can be customized
Weave Type: Plain weave, dutch weave, twill weave, crimped.
Features
Heating resistance.
Oxidation resistance.
Sulfur resistance.
Anti-carburizing.
High surface load.
Long lasting and durable.
Low temperature coefficient of resistance.
Max Working Temperature
1Cr13Al4 - 950 ℃
1Cr21Al4 - 1100 ℃
0Cr21Al6 - 1250 ℃
0Cr23Al5 - 1250 ℃
0Cr25Al5 - 1250 ℃
0Cr21Al6Nb - 1350 ℃
0Cr27Al7Mo2 - 1400 ℃
